2026 Isuzu FY Series

ISUZU FYJ 320-355 AT R67

Heavy Duty 10x4 Cab Chassis

VEHICLE OVERVIEW

Model: FYJ 320-355 AT R67
GVM: 32,000 kg
GCM: 45,000 kg
Wheelbase: 6,700 mm
Engine: Isuzu 6UZ1-TCC 6 Cylinder Turbo Diesel
Power: 259 kW @ 2,000 rpm
Torque: 1,437 Nm @ 1,400 rpm
Transmission: Allison 4430 GEN 6 6-Speed Automatic Transmission (AT)

SINCLAIR

Bisalloy Steel Tipping body

7.2m long x 2440mm wide
1100mm high fixed sides
Side swing tailgate
5mm floor and sides
Well mounted hoist
PTO & Pump to suit automatic transmission
Access ladder on both sides of tipping body
1 alloy toolboxes on both sides of tipping body in between cab and tipping body
1 PVC electric wind out tarp system suitable for hot mix
Supply grain locks on tailgate
Provisions for reversing camera inside of tipping body
Supply rear crash bar
Supply rear wing on back of tipping body 200mm wide
Painted in green 2 pack – customer to supply paint code
Lights & signs to RMS specifications
Blue plate
Hendrickson HEX13 lifting pusher axle
Dock Leveler to lift or lower Airbags on Truck

ARMOURY GROUP

Armour Brite Alloy Wheel

FEATURES

ADR 80/04 (Euro VI) Compliant
Adaptive Driving Beam (ADB)
Bi-LED Headlamps with Daytime Running Lamps (DRL)
Electronic Stability Control (ESC)
Full Speed Adaptive Cruise Control (FACC)
ISRI 6860/875 NTS2 Air Suspension Driver's Seat
Lane Departure Warning (LDW)
Lane Keeping Assist (LKA)

CHASSIS

Front Axle Capacity: 14,600 kg
Rear Axle Capacity: 20,000 kg
Fuel Tank: 400 L Aluminium
AdBlue Tank: 28 L High-Density Polyethylene
1st Steer Axle Tyres: 295/80R22.5 152/148M Michelin X Multi Z2
2nd Steer Axle Tyres: 295/80R22.5 152/148M Michelin X Multi Z2
Hendrickson Steerable Lift up Pusher Axle
Rear Axle Tyres: 11R22.5 148/145L Michelin

CABIN

Automatic Climate Control
ISRI 6860/875 NTS2 Air Suspension Driver's Seat with Heating and Ventilation
10.1" High Definition Touchscreen
Truck Tailored GPS Navigation with Live Traffic and Map Content Updates
Android Auto & Apple CarPlay Compatible
Wi Fi Connectivity
Bi LED Headlamps with Daytime Running Lamps (DRL)
LED Front Fog Lamps
LED Tail Lamps
Reverse Alarm

WARRANTY & SERVICE

Chassis Warranty: 6 Years / 600,000 km / 10,000 Engine Hours
Service Interval: 25,000 km / 12 Months / 500 Hours (Whichever Occurs First)
Roadside Assist: 6 Years / 24/7 Unlimited km
